Aluminum Surface Treatment Types
In CNC manufacturing, aluminum is widely used due to its lightweight nature, high strength, and corrosion resistance. However, untreated aluminum surfaces are prone to oxidation and wear, limiting their performance in demanding environments. Proper surface treatments can significantly enhance aluminum's functionality and aesthetics. This blog provides a detailed overview of common aluminum surface treatment processes and their applications.
Anodizing
Principle: Electrolytic formation of a dense oxide layer (Al₂O₃) on the aluminum surface.
Key Features
Superior performance characteristics that set anodized aluminum apart from standard materials.
- • Corrosion resistance (up to 10× better than untreated aluminum)
- • Increased surface hardness (Mohs hardness: 3–9)
- • Dyeability (colors include black, silver, gold, etc.)
Applications
Versatile solutions across multiple industries and use cases.
Electronics
Laptop/phone casings
Architecture
Aluminum windows, curtain walls
Industrial parts
Heat sinks, fixtures
Passivation (Chromate Conversion Coating)
Principle: Passivation, also referred to as chromate conversion coating, is an acid-based surface treatment process. It creates a passive oxide film on the metal surface to significantly enhance corrosion and oxidation resistance.
Superior Protection: Achieves remarkable protection with an ultra-thin coating (0.5-5μm), improving aluminum's salt spray resistance by 10-50 times.
Process Simplicity: Requires only seconds to minutes of immersion time, making it ideal for high-volume production.
Excellent Compatibility: Can be combined with painting, anodizing and other processes to form composite protection systems; For example, increases paint adhesion by 40% when used as a pretreatment.
Aerospace
Aircraft skin components.
Consumer Electronics
Aluminum alloy frames for smartphones.
Automotive:
Battery enclosures and housings.
Electroplating
Principle: Depositing metal layers (e.g., nickel, copper, chromium) onto aluminum surfaces through electrochemical processes.
Key Features
Enhances electrical conductivity (e.g., silver plating for high-frequency connectors).
Improves decorative appearance (e.g., chrome plating for mirror finishes).
Requires pre-treatment with zinc immersion or electroless nickel plating (direct electroplating on aluminum has poor adhesion).
Applications
Electronic products
(USB interfaces, heat sinks).
Automotive decorative parts
(nameplates, door handles).
Spray Coating
Technology: Including powder coating and liquid spraying.
Key Features
Diverse color options and strong weather resistance.
Powder coating is more environmentally friendly with no VOC emissions.
Applications
Household appliance casings
(refrigerators, air conditioners).
Architectural aluminum panels
(painted aluminum curtain walls).
Polishing
Principle: Mechanical processing to create surface textures or mirror effects.
Key Features
Enhances aesthetic appeal (e.g., smartphone middle frames, luxury packaging).
Can be combined with anodizing to improve durability.
Categories
Straight wire drawing (regular texture)
Brushed random texture (irregular artistic effect)
Mirror polishing (reflectivity > 90%)
Laser Engraving
Technology: Including laser cleaning, laser texturing, laser etching, etc.
Key Features
Precise control (micron-level processing)
No chemical pollution
Applications
LOGO engraving for 3C products
Lightweight automotive components (weight reduction and enhanced bonding force)
Summary:
Selecting the appropriate aluminum profile surface treatment technology should comprehensively consider factors such as the application environment, aesthetic requirements, cost budget, and maintenance requirements.
